UFTG - FRONT TERMINAL GEL SERIES
This series is specifically designed for 19 or 23 inch power cabinets. The front terminals make the installation and maintenance easy. The unique valve design reduces water loss and prevents air going inside the battery.
UFTG Series VRLA batteries can be used for:
Network connection equipment of communication system
Power system of special network or local area network
UPS, Standby
Power Station Systems
Which voltage would you like to view?
UFTG - FRONT TERMINAL GEL SERIES - 12V
| Battery Model | Voltage (V) | Capacity (20hr) | Capacity (10hr) | Length (±3mm) | Width (±3mm) | Height (±3mm) | Total Height (±3mm) | Weight (kg) | Terminal Type | Design Life (Years) |
|---|---|---|---|---|---|---|---|---|---|---|
| UFTG70-12 | 12 | 70.00 | 65.80 | 564.00 | 114.00 | 187.00 | 187.00 | 26.00 | F6 | 12+ |
| UFTG100-12 | 12 | 90.00 | 85.00 | 508.00 | 110.00 | 232.50 | 232.50 | 32.30 | F6 | 12+ |
| UFTG100-12S | 12 | 96.00 | 90.00 | 394.00 | 110.00 | 285.00 | 285.00 | 35.00 | F6 | 12+ |
| UFTG100-12L | 12 | 100.00 | 95.00 | 560.00 | 125.00 | 228.00 | 228.00 | 35.60 | F6 | 12+ |
| UFTG100-12L | 12 | 100.00 | 95.00 | 506.00 | 110.00 | 224.00 | 239.00 | 35.60 | F6 | 12+ |
| UFTG120-12 | 12 | - | 120.00 | 551.00 | 110.00 | 239.00 | 239.00 | 36.00 | F11 | 12+ |
| UFTG150-12 | 12 | 162.00 | 150.00 | 551.00 | 110.00 | 287.00 | 287.00 | 45.00 | F6 | 12+ |
| UFTG180-12 | 12 | - | 180.00 | 550.00 | 126.00 | 280.00 | 280.00 | 52.00 | F11 | 12+ |
