UHR - HIGH RATED SERIES
These series features silver-coated terminals, which improve the electric conductivity. To optimize high rate performance a unique paste formula have been applied to the plate technology.
This series also features AGM separators, which use less electrical resistance to improve the current.
UHR Series VRLA batteries can be used for:
High Rate UPS
High Power Backup Supply
Emergency Power Supply
Power Tools
Emergency Lighting
Electric Starting
UHR - HIGH RATED UPS SERIES - 2V
| Battery Model | Voltage (V) | Capacity (20hr) | Capacity (10hr) | W15 (1.67V/cell) | Length (±3mm) | Width (±3mm) | Height (±3mm) | Total Height (±3mm) | Weight (kg) | Terminal Type | Design Life (Years) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| UHR200-2 | 2 | - | 200.00 | 593.00 | 170.00 | 110.00 | 328.00 | 343.00 | 13.10 | F11 | 16 |
| UHR300-2 | 2 | - | 300.00 | 857.00 | 170.00 | 150.00 | 330.00 | 345.00 | 18.10 | F11 | 16 |
| UHR400-2 | 2 | - | 400.00 | 1186.00 | 175.00 | 210.00 | 330.00 | 345.00 | 26.40 | F11 | 16 |
| UHR500-2 | 2 | - | 500.00 | 1450.00 | 175.00 | 240.00 | 328.00 | 343.00 | 31.10 | F11 | 16 |
| UHR600-2 | 2 | - | 600.00 | 1714.00 | 175.00 | 300.00 | 330.00 | 345.00 | 37.20 | F11 | 16 |
| UHR800-2 | 2 | - | 800.00 | 2372.00 | 175.00 | 410.00 | 330.00 | 345.00 | 52.90 | F11 | 16 |
| UHR1000-2 | 2 | - | 1000.00 | 2900.00 | 175.00 | 475.00 | 328.00 | 343.00 | 62.00 | F11 | 16 |
UHR - HIGH RATED UPS SERIES - 6V
| Battery Model | Voltage (V) | Capacity (20hr) | Capacity (10hr) | W15 (1.67V/cell) | Length (±3mm) | Width (±3mm) | Height (±3mm) | Total Height (±3mm) | Weight (kg) | Terminal Type | Design Life (Years) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| UHR100-6 | 6 | - | 100.00 | 381.00 | 195.00 | 170.00 | 205.00 | 210.00 | 16.50 | F6 | 12 |
| UHR150-6 | 6 | 160.60 | 150.00 | 535.00 | 260.00 | 180.00 | 245.00 | 250.00 | 21.50 | F11 | 12 |
| UHR200-6 | 6 | - | 206.00 | 675.80 | 322.00 | 178.00 | 226.00 | 232.00 | 30.30 | F11 | 12 |
UHR - HIGH RATED UPS SERIES - 12V
| Battery Model | Voltage (V) | Capacity (20hr) | Capacity (10hr) | W15 (1.67V/cell) | Length (±3mm) | Width (±3mm) | Height (±3mm) | Total Height (±3mm) | Weight (kg) | Terminal Type | Design Life (Years) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| UHR2.2-12 | 12 | - | 2.13 | 8.19 | 178.00 | 35.00 | 60.00 | 66.00 | 0.97 | F2 / F1 | 12 |
| UHR5.4-12 | 12 | - | 5.40 | 24.00 | 90.00 | 70.00 | 101.00 | 107.00 | 1.80 | F2 / F1 | 12 |
| UHR6.5-12 | 12 | - | 6.69 | 25.30 | 151.00 | 51.00 | 93.00 | 99.00 | 1.90 | F2 / F1 | 12 |
| UHR7-12 | 12 | - | 7.23 | 29.00 | 151.00 | 65.00 | 93.50 | 99.00 | 2.45 | F2 / F1 | 12 |
| UHR7.6-12 | 12 | - | 7.88 | 32.20 | 151.00 | 65.00 | 93.50 | 99.00 | 2.45 | F2 / F1 | 12 |
| UHR9-12 | 12 | 9.00 | 7.98 | 33.30 | 151.00 | 65.00 | 93.50 | 99.00 | 2.66 | F2 / F1 | 12 |
| UHR12-12 | 12 | - | 12.60 | 49.80 | 151.00 | 98.00 | 95.00 | 101.00 | 4.05 | F2 / F1 | 12 |
| UHR17-12 | 12 | - | 17.60 | 63.40 | 181.50 | 77.00 | 167.50 | 167.50 | 5.78 | F3 | 12 |
| UHR18-12 | 12 | - | 18.70 | 67.40 | 181.50 | 77.00 | 167.50 | 167.50 | 6.00 | F3/F12 | 12 |
| UHR20-12 | 12 | - | 20.40 | 81.40 | 181.50 | 77.00 | 166.50 | 166.50 | 6.90 | F12 | 12 |
| UHR24-12 | 12 | - | 25.50 | 99.80 | 166.50 | 175.00 | 125.00 | 125.00 | 8.60 | F3/F12 | 12 |
| UHR27-12 | 12 | 27.00 | 26.10 | 92.80 | 164.00 | 125.00 | 172.00 | 175.00 | 7.90 | F12 | 12 |
| UHR35-12 | 12 | - | 35.00 | 120.10 | 195.00 | 130.00 | 164.00 | 180.00 | 10.50 | F10 | 12 |
| UHR38-12 | 12 | - | 38.70 | 126.30 | 197.00 | 165.00 | 170.00 | 170.00 | 13.20 | F6 | 12 |
| UHR40-12 | 12 | - | 40.00 | 120.00 | 197.00 | 165.00 | 170.00 | 170.00 | 13.00 | F6 | 12 |
| UHR45-12 | 12 | - | 45.00 | 160.00 | 197.00 | 165.00 | 170.00 | 170.00 | 14.20 | F6 | 12 |
| UHR50-12 | 12 | 55.00 | 52.60 | 240.80 | 229.00 | 138.00 | 200.00 | 203.00 | 17.70 | F6 | 12 |
| UHR55-12 | 12 | - | 55.00 | 185.00 | 229.00 | 138.00 | 205.00 | 211.00 | 16.20 | F6 | 12 |
| UHR65-12 | 12 | 67.40 | 65.00 | 221.20 | 348.00 | 167.00 | 178.00 | 178.00 | 21.20 | F6 | 12 |
| UHR75-12 | 12 | 76.00 | 75.00 | 237.70 | 259.00 | 168.00 | 208.00 | 214.00 | 22.30 | F6/F9 | 12 |
| UHR80-12 | 12 | 82.00 | 78.60 | 324.60 | 259.00 | 168.00 | 208.00 | 211.00 | 24.20 | F6 | 12 |
| UHR95-12 | 12 | 95.00 | 90.70 | 374.00 | 308.00 | 168.00 | 211.00 | 216.00 | 28.50 | F6 | 12 |
| UHR100-12 | 12 | 102.00 | 100.00 | 356.10 | 330.00 | 173.00 | 212.00 | 220.00 | 30.60 | F11 | 12 |
| UHR120-12 | 12 | 126.00 | 120.00 | 483.80 | 410.00 | 177.00 | 225.00 | 225.00 | 37.30 | F11 | 12 |
| UHR142-12 | 12 | 142.00 | 136.00 | 490.90 | 335.00 | 172.00 | 275.00 | 278.00 | 42.00 | F8 | 12 |
| UHR150-12 | 12 | - | 155.00 | 487.50 | 485.00 | 170.00 | 238.50 | 240.00 | 43.20 | F11 | 12 |
| UHR155-12 | 12 | 155.00 | 147.00 | 540.10 | 342.00 | 172.00 | 280.00 | 285.00 | 42.60 | F6 | 12 |
| UHR200-12 | 12 | - | 206.00 | 675.80 | 522.00 | 240.00 | 218.00 | 224.00 | 62.20 | F11 | 12 |
| UHR225-12 | 12 | - | 225.00 | 765.00 | 522.00 | 240.00 | 218.00 | 224.00 | 64.80 | F11 | 12 |
| UHR250-12 | 12 | 257.00 | 250.00 | 783.30 | 522.00 | 268.00 | 220.00 | 226.00 | 72.50 | F11 | 12 |
